型号

名称

执行标准

CHVV80/DA

聚氯乙烯绝缘聚氯乙烯护套镀锡铜丝编织铠装单根阻燃船用通信电缆

IEC60092-376IEC60092-351
IEC60092-359
IEC60228
IEC60332-1

CHVV90/DA

聚氯乙烯绝缘聚氯乙烯护套镀锌钢丝编织铠装单根阻燃船用通信电缆

CHVV80/SA

聚氯乙烯绝缘聚氯乙烯护套镀锡铜丝编织铠装成束阻燃船用通信电缆

IEC60092-376
IEC60092-351
IEC60092-359
IEC60228
IEC60332-3A

CHVV90/SA

聚氯乙烯绝缘聚氯乙烯护套镀锌钢丝编织铠装成束阻燃船用通信电缆

CHVV82/DA

聚氯乙烯绝缘聚氯乙烯内护套镀锡铜丝编织铠装聚氯乙烯外护套单根阻燃船用通信电缆

IEC60092-376 IEC60092-351
IEC60092-359 IEC60228
IEC60332-1

CHVV92/DA

聚氯乙烯绝缘聚氯乙烯内护套镀锌钢丝编织铠装聚氯乙烯外护套单根阻燃船用通信电缆

CHVV82/SA

聚氯乙烯绝缘聚氯乙烯内护套镀锡铜丝编织铠装聚氯乙烯外护套成束阻燃船用通信电缆

IEC60092-376 IEC60092-351 IEC60092-359 IEC60228
IEC60332-3A

CHVV92/SA

聚氯乙烯绝缘聚氯乙烯内护套镀锌钢丝编织铠装聚氯乙烯外护套成束阻燃船用通信电缆

CHVVP80/DA

聚氯乙烯绝缘铜丝编织对绞屏蔽聚氯乙烯护套镀锡铜丝编织铠装单根阻燃船用通信电缆

IEC60092-376
IEC60092-351
IEC60092-359
IEC60228
IEC60332-1

CHVVP90/DA

聚氯乙烯绝缘铜丝编织对绞屏蔽聚氯乙烯护套镀锌钢丝编织铠装单根阻燃船用通信电缆

CHVVP80/SA

聚氯乙烯绝缘铜丝编织对绞屏蔽聚氯乙烯沪套镀锡铜丝编织铠装成束阻燃船用通信电缆

IEC60092-376
IEC60092-351
IEC60092-359
IEC60228
IEC60332-3A

CHVVP90/SA

聚氯乙烯绝缘铜丝编织对绞屏蔽聚氯乙烯沪套镀锌钢丝编织铠装成束阻燃船用通信电缆

CHVVP82/DA

聚氯乙烯绝缘铜丝编织对绞屏蔽聚氯乙烯内护套镀锡铜丝编织铠装聚氯乙烯外护套单根阻燃船用通信电缆

IEC60092-376
IEC60092-351
IEC60092-359
IEC60228
IEC60332-1

CHVVP92/DA

聚氯乙烯绝缘铜丝编织对绞屏蔽聚氯乙烯内护套镀锌钢丝编织铠装聚氯乙烯外护套单根阻燃船用通信电缆

CHVVP82/SA

聚氯乙烯绝缘铜丝编织对绞屏蔽聚氯乙烯内护套镀锡铜丝编织铠装聚氯乙烯外护套成束阻燃船用通信电缆

CHVVP92/SA

聚氯乙烯绝缘铜丝编织对绞屏蔽聚氯乙烯内护套镀锌钢丝编织铠装聚氯乙烯外护套成束阻燃船用通信电缆

IEC60092-376
IEC60092-351
IEC60092-359
IEC60228
IEC60332-3A

CHV82/DA

聚氯乙烯绝缘铜丝编织总屏蔽聚氯乙烯外护套单根阻燃船用通信电缆

IEC60092-376
IEC60092-351
IEC60092-359
IEC60228
IEC60332-1

CHV8290/DA

聚氯乙烯绝缘铜丝编织总屏蔽聚氯乙烯护套镀锌钢丝编织铠装单根阻燃船用通信电缆

CHV8292/DA

聚氯乙烯绝缘铜丝编织总屏蔽聚氯乙烯内护套镀锌钢丝编织铠装聚氯乙烯外护套单根阻燃船用通信电缆

CHV82/SA

聚氯乙烯绝缘铜丝编织总屏蔽聚氯乙烯外护套成束阻燃船用通信电缆

IEC60092-376
IEC60092-351
IEC60092-359
IEC60228
IEC60332-3A

CHV8290/SA

聚氯乙烯绝缘铜丝编织总屏蔽聚氯乙烯护套镀锌钢丝编织铠装成束阻燃船用通信电缆

CHV8292/SA

聚氯乙烯绝缘铜丝编织总屏蔽聚氯乙烯内护套镀锌钢丝编织铠装聚氯乙烯外护套成束阻燃船用通信电缆

CHVP82/DA

聚氯乙烯绝缘铜丝编织对绞屏蔽铜丝编织总屏蔽聚氯乙烯外护套单根阻燃船用通信电缆

IEC60092-376
IEC60092-351
IEC60092-359
IEC60228
IEC60332-1

CHVP82/SA

聚氯乙烯绝缘铜丝编织对绞屏蔽铜丝编织总屏蔽聚氯乙烯外护套成束阻燃船用通信电缆

IEC60092-376
IEC60092-351
IEC60092-359
IEC60228
IEC60332-3A

芯数×导体标称截面(mm2)

CHVV80/DA,SA CHVV90/DA,SA

CHVV82/DA,SA CHVV92/DA,SA

计算外径(mm)

计算重量(kg/km)

计算外径(mm)

计算重量(kg/km)

标称值

最大值

CHVV80

CHVV90

标称值

最大值

CHVV82

CHVV92

1×2×0.5

7.3

8.2

86

87

8.9

10.0

118

113

2×2×0.5

10.5

12.0

152

154

12.3

13.5

202

194

3×2×0.5

11.5

13.0

212

210

13.3

15.0

266

254

4×2×0.5

12.7

14.0

247

244

14.5

16.0

306

293

5×2×0.5

13.7

15.0

285

282

15.5

17.0

348

334

7×2×0.5

14.7

16.0

337

334

16.7

18.5

413

397

10×2×0.5

18.7

20.5

471

466

20.9

22.5

576

556

12×2×0.5

19.3

21.0

519

515

21.5

23.5

627

606

14×2×0.5

20.2

22.0

572

568

22.4

24.0

686

664

19×2×0.5

22.5

24.5

716

711

24.9

27.0

853

829

24×2×0.5

26.4

28.5

902

896

29.0

31.0

1076

1047

27×2×0.5

27.0

29.0

970

963

29.6

32.0

1147

1118

30×2×0.5

27.9

30.0

1045

1039

30.5

33.0

1229

1198

37×2×0.5

30.2

32.5

1235

1228

33.0

35.5

1449

1415

48×2×0.5

35.2

37.5

1667

1646

38.2

41.0

1933

1881

1×2×0.75

7.7

8.8

101

102

9.3

10.5

134

128

2×2×0.75

11.7

13.0

207

205

13.5

15.0

262

250

3×2×0.75

12.3

13.5

242

239

14.1

15.5

299

286

4×2×0.75

13.5

15.0

294

291

15.3

17.0

357

342

5×2×0.75

14.6

16.0

331

328

16.6

18.0

407

391

7×2×0.75

16.0

17.5

406

402

18.0

19.5

488

470

10×2×0.75

20.1

22.0

556

551

22.3

24.0

668

647

12×2×0.75

20.9

22.5

628

624

23.1

25.0

746

723

14×2×0.75

21.9

23.5

697

692

24.1

26.0

819

795

19×2×0.75

24.4

26.5

877

871

26.8

29.0

1025

999

24×2×0.75

28.5

30.5

1089

1083

31.1

33.5

1277

1245

27×2×0.75

29.3

31.5

1192

1185

31.9

34.0

1384

1352

30×2×0.75

30.3

32.5

1289

1282

33.1

35.5

1503

1470

37×2×0.75

33.3

35.5

1629

1609

36.1

38.5

1864

1815

48×2×0.75

38.2

41.0

2051

2028

41.4

44.0

2359

2303
